10Base5

Definition of the noun 10base5

What does 10base5 mean as a name of something?

noun

  1. IEEE 802.3 Ethernet standard using a type of cable called Thick Ethernet or RG-8 which is thick and yellow and has markings at every 2.5 meters, which designation means the following: (1) the cable transmission speed is 10 Mbps, (2) the transmission is in baseband, and (3) the length of the cable should be no more than 500 meters.

Explanation

10BASE5 was the original commercially available variant of Ethernet. For its physical layer it used cable similar to RG-8/U coaxial cable but with extra braided shielding. This is a stiff, 0.375-inch diameter cable with an impedance of 50 ohms, a solid center conductor, a foam insulating filler, a shielding braid, and an outer jacket. The outer sheath was often yellow-to-orange/brown foam fluorinated ethylene propylene so it often is called "yellow cable", "orange hose", or sometimes humorously "frozen yellow garden hose".

Printed dictionaries and other books with definitions for 10Base5

Click on a title to look inside that book (if available):

Google previewComputer Networks (2008)

by I.A.Dhotre V.S.Bagad

The notation 10BASE5 means that it operates at 10 Mbps, uses baseband signaling and can support segment upto 500 metres. The length of the network can be extended using repeaters. The standard allows a maximum of four repeaters in ...

Google previewNetworking Technology for Digital Devices (2009)

by V.S.Bagad, I.A.Dhotre

The notation 10BASE5 means that it operates at 10 Mbps, uses baseband signaling and can support segment upto 500 metres. The length of the network can be extended using repeaters. The standard allows a maximum of four repeaters in ...

Google previewELECTRONIC INSTRUMENTS AND INSTRUMENTATION TECHNOLOGY (2004)

by M. M. S. ANAND

10Base5 is a standard Ethernet implementation that uses RG-58 coaxial cable segments up to 500 metres long. Transceivers are clamped on to the segment, with a minimum distance between transceivers of 2.5 metres. A transceiver cable (or ...

Google previewComputer Communication Networks (2009)

by V.S.Bagad, I.A.Dhotre

The notation 10BASE5 means that it operates at 10 Mbps, uses baseband signaling and can support segment upto 500 metres. The length of the network can be extended using repeaters. The standard allows a maximum of four repeaters in ...

Google previewMECHANICAL SCIENCES (2004)

ENGINEERING MECHANICS AND STRENGTH OF MATERIALS by AKSHAY RANJAN PAUL, PIJUSH ROY, SACHAYAN MUKHERJEE

10Base5 is a standard Ethernet implementation that uses RG-58 coaxial cable segments up to 500 metres long. Transceivers are clamped on to the segment, with a minimum distance between transceivers of 2.5 metres. A transceiver cable (or ...

Google previewNetwork Safety (2010)

by EC-Council

The 10Base5 is a bus topology. To overcome the size limitation of LANs, networking devices such as repeaters and bridges are used. In thick Ethernet, each segment has a restricted length of 500 meters. In order to reduce the number of ...

Google previewUnderstanding TCP/IP (2006)

A Clear and Comprehensive Guide to TCP/IP Protocols by Libor Dostálek, Alena Kabelová

10BASE5 means that it is a network using the transmission frequency of 10 MHz ( that, for Ethernet, also equals the theoretical transmission rate of the network). The massive expansion of Ethernet came with the use of. Figure 4.32: The ...

Google previewDictionary of Computing (2010)

by A & C Black Publishers Ltd

protocol and signalling method of a local area network COMMENT: Ethernet has several implementations: 10Base5 is a bus-based topology running over coaxial cable; 10BaseT uses unshielded-twisted-pair cable in a star-based topology; ...

Google previewThe Froehlich/Kent Encyclopedia of Telecommunications (1995)

Volume 10 - Introduction to Computer Networking to Methods for Usability Engineering in Equipment Design by Fritz E. Froehlich, Allen Kent

versions (10BASE5 network); they both use the same MAC. The difference lies in the structure of the frame. Next, we describe the Ethernet network in some detail. The Ethernet network consists ...

Google previewEncyclopedia Of Information Technology (2007)

by Atlantic

10BASE5 (also known as thicknet) is the original "full spec" variant of Ethernet cable, using RG-8 (Radio Grade - 8) coaxial cable. A stiff, large diameter cable with an impedance of 50 ohms and with multiple shielding. The outer sheath is often ...

Google previewBlackie’s Dictionary of Computer Science

by Blackie

10base5, where X is the data rate in Mbps, base means baseband (as opposed to ...

Google previewDictionary of Information Technology (2010)

by Ramesh Bangia

A transceiver cable used to connect a host adapter within a computer to an Ethernet (10base5 or lOBaseF) network. See also 10Base5, lOBase-F, Ethernet ( definition 1), transceiver cable. AUI 1. Acronym for attachment unit interface. A 15 - pin ...

Google previewRadiological Sciences Dictionary: Keywords, names and definitions (2009)

by David Dowsett

10BASE5 (clin) An IEEE 802.3 media standard for a 10Mbits per second baseband, ...

Google previewFocal Illustrated Dictionary of Telecommunications (2013)

by Xerxes Mazda, Fraidoon Mazda

10Base5: Standard for running Ethernet LAN over thick coaxial cable. The term is derived from the fact that the system can run at 10 Mbit/s speed (BASEband) over 500 metres maximum length. 10BaseT: Standard for running Ethernet LAN ...

Google previewA Dictionary of Computer Science (2016)

by Andrew Butterfield, Gerard Ekembe Ngondi, Anne Kerr

The original CSMA/CD standard specified a coaxial cable with an overall diameter of about 10 mm; this allowed data to be presented as a baseband signal at 10 Mbps, with a range of 500 yards, and is referred to as thick wire or 10base5 ...

Google previewConcise Encyclopedia of Computer Science (2004)

by Edwin D. Reilly

For example, 10Base5 refers to 1 ...

Google previewComputer Technology Encyclopedia (2008)

by Michael Graves

10Base5 IO-Mb Ethernet over thicknet coaxial cable. Cable runs up to 500 m are possible. A device called a vampire clamp is used to tap into the wire.

Google previewDictionary of e-Business (2003)

A Definitive Guide to Technology and Business Terms by Francis Botto

10base5 An industry name for basic Ethernet LAN technology. Network computers /devices are fitted with Ethernet cards (or chipsets) and are connected using coaxial cables. It provides 10 Mbits/sec data rates up to a distance of 500 m .

Google previewComprehensive Dictionary of Electrical Engineering (1999)

by Phillip A. Laplante

10base5 nect nodes on an Ethernet network. The 10 refers to the transfer rate used on standard Ethernet, 10 megabits per second. The base means that the network uses baseband communication rather than broadband communications, and ...

Google previewDictionary of Computer Science, Engineering and Technology (2000)

by Philip A. Laplante

This type of cable is also called "thin" Ethernet because it is a smaller diameter cable than the 10base5 cables. lObaseS a type of coaxial cable used to connect nodes on an Ethernet network. The 10 refers to the transfer rate used on standard ...
